NNF Full complement cylindrical roller bearings

Tips:
1. The bearing does not have a stop ring, if the user needs, please specify when ordering.

2. When the user needs, the bearing can be surface treated and the dimensional accuracy is before treatm ent.

3. Type suffix character explanation
N-first position, indicating that the bearing outer ring has an improved stop ring groove.
2P-second position, indicating rubber cover seal, inner ring double assembly with stop buckle ring
2Z-second position, indicating metal cover seal, inner ring double assembly without stop buckle ring
V-third position, full roller (no cage).

4. The inner ring must be axially positioned.

+86-513-80311111 / +86-15050632597 [email protected]

Get Free Quotes

About Us

Jiangsu Wanda Special Bearing Co., Ltd.,

Jiangsu Wanda Special Bearing Co., Ltd. is a national high-tech enterprise and was formerly known as the state-owned Rugao Bearing Factory. Jiangsu Wanda Special Bearing Co., Ltd. is wholesale OEM/ODM NNF Full complement cylindrical roller bearings suppliers and NNF Full complement cylindrical roller bearings factory. The company was founded in 1969 and transformed into a private enterprise in 2001. It has a history of more than 50 years of professional research and development, manufacturing and sale of bearings. It was the country's first designated manufacturer of mast guideand chain roller bearings. the lead company in the drafting of JB/T7360 technical standards and one of the country's first batch of specialized new "Little Giant" enterprises.

Certificate Of Honor

News

Forklift side rollers: balance guardians for rugged terrain
19 Dec, 2024
1. The mechanism of forklift side rollersForklift side rollers, as the name sugg...
READ MORE
Forklift cross guide bearings: a stable foundation for heavy cargo handling
12 Dec, 2024
1. Challenges of heavy cargo handlingHeavy cargo handling is not just a simple p...
READ MORE
Forklift gantry sprocket bearing: a precision power core to improve loading and unloading efficiency
05 Dec, 2024
1. Structure and design of forklift gantry sprocket bearingAs the name implies, ...
READ MORE
Exploration of the application of forklift mast guide bearings and PI tubes in medical stents
28 Nov, 2024
Forklift mast guide bearings: the stable cornerstone of logistics handlingIn bus...
READ MORE
Forklift Gantry Sprocket Bearing: The key to reasonable operation and maintenance
22 Nov, 2024
1. Reasonable operation of forklift to reduce the wear of Forklift Gantry Sprock...
READ MORE

Bearing No.	Dimension(mm)										Weight(kg)
Bearing No.	d	D	C/B	Cr(KN)	Cor(KN)	Cf(+0.20)	D1	m	r(min)	X	Weight(kg)
NNF5008N2PV	40	68	38/37	80	112	32.2	65.8	2.7	0.6	28.5	0.56
NNF5009N2PV	45	75	40/39	105	153	34.2	72.8	2.7	0.6	30.5	0.7
NNF5010N2PV	50	80	40/39	108	168	34.2	77.8	2.7	0.6	30.5	0.76
NNF5011N2PV	55	90	46/45	125	190	40.2	87.4	3.2	0.6	36	1.18
NNF5012N2PV	60	95	46/45	130	200	40.2	92.4	3.2	0.6	36	1.26
NNF5013N2PV	65	100	46/45	135	220	40.2	97.4	3.2	0.6	36	1.33
NNF5014N2PV	70	110	54/53	198	290	48.2	107.1	4.2	0.6	42	1.87
NNF5015N2PV	75	115	54/53	205	320	48.2	112.1	4.2	0.6	42	1.96
NNF5016N2PV	80	125	60/59	250	425	54.2	122.1	4.2	0.6	48	2.71
NNF5017N2PV	85	130	60/59	270	447	54.2	127.1	4.2	0.6	48	2.83
NNF5018N2PV	90	140	67/66	305	550	59.2	137	4.2	0.6	54	3.71
NNF5019N2PV	95	145	67/66	320	580	59.2	142	4.2	0.6	54	3.88
NNF5020N2PV	100	150	67/66	336	585	59.2	147	4.2	0.6	54	3.95
NNF5022N2PV	110	170	80/79	400	700	70.2	167	4.2	0.6	64	6.57
NNF5024N2PV	120	180	80/79	430	760	71.2	176	4.2	0.6	64	7.04
NNF5026N2PV	130	200	95/94	610	1050	83.2	196	4.2	0.6	77	10.5
NNF5028N2PV	140	210	95/94	630	1140	83.2	206	5.2	0.6	77	11.1
NNF5030N2PV	150	225	100/99	730	1284	87.2	221	5.2	0.6	80	13.3
NNF5032N2PV	160	240	109/108	870	1540	95.2	236	5.2	0.6	89	16.6
NNF5034N2PV	170	260	122/121	990	1780	107.2	254	5.2	0.6	100	22.6
NNF5036N2PV	180	280	136/135	1166	2160	118.2	274	5.2	0.6	112	30.1
NNF5038N2PV	190	290	136/135	1184	2240	118.2	284	5.2	0.6	112	31.5
NNF5040N2PV	200	310	150/149	1368	2700	128.2	304	6.3	0.6	126	40.8
NNF5044N2PV	220	340	160/159	1576	3100	138.2	334	6.3	1	132	52.5
NNF5048N2PV	240	360	160/159	1690	3347	138.2	354	6.3	1	132	56
NNF5052N2PV	260	400	190/189	2250	4550	162.2	394	6.3	1.1	150	84.5
NNF5056N2PV	280	420	190/189	2380	4780	163.2	413	7.3	1.1	150	90
NNF5060N2PV	300	460	218/216	2965	5870	185.2	453	7.3	1.1	170	126
