Wholesale OEM/ODM NNTR Full complement cylindrical roller bearings

Home / Product / Cylindrical Roller Bearings / NNTR Full complement cylindrical roller bearings

NNTR Full complement cylindrical roller bearings

Tips:
1. The bearing does not have a stop ring, if the user needs, please specify when ordering.
2. When the user needs, the bearing can be surface treated and the dimensional accuracy is before treatm ent.
3. Type suffix character explanation
N-first position, indicating that the bearing outer ring has an improved stop ring groove.
2P-second position, indicating rubber cover seal, inner ring double assembly with stop buckle ring
2Z-second position, indicating metal cover seal, inner ring double assembly without stop buckle ring
V-third position, full roller (no cage).
4. The inner ring must be axially positioned.
+86-513-80311111 / +86-15050632597 [email protected]
contact us
PREV: NUTR Full complement cylindrical roller bearings NEXT:No next article
  • Parameter
  • Dimensions
  • Get A Free Quote

Dimensions(mm) Rated load(kN) Limiting speed Bearing No.
d D B H R r Cr Cor RPM
50 130 63 65 10000 3 229 290 1100 NNTR50-130
55 120 40 43 10000 2 170 260 1000 NNTR55-120
55 140 68 70 10000 3 280 370 850 NNTR55-140
60 150 73 75 10000 3 320 435 800 NNTR60-150
65 160 75 75 10000 3 340 455 700 NNTR65-160
70 180 83 85 10000 3 435 600 600 NNTR70-180
80 200 88 90 10000 4 510 710 500 NNTR80-200
90 220 98 100 10000 4 650 950 400 NNTR90-220
100 240 103 105 10000 4 740 1130 340 NNTR100-240
110 260 113 115 10000 4 880 1370 300 NNTR110-260
120 290 133 135 15000 4 1150 1790 260 NNTR120-29C
130 310 144 146 15000 5 1320 2080 240 NNTR130-310
140 340 160 162 15000 5 1620 2600 200 NNTR140-340
150 360 171 173 15000 5 1810 2950 180 NNTR150-360
