Wholesale OEM/ODM WDB-110-xx-x Crossed roller slewing ring without gear

Home / Product / Slewing Bearings / WDB-110-xx-x Crossed roller slewing ring without gear

WDB-110-xx-x Crossed roller slewing ring without gear

Heat treatment of slewing bearing gear
Due to the need of transmitting force or torque, one ferrule of slewing bearing is provided with teeth. The heat treatment state of gear is often normalizing or tempering According to different application scenarios, the gear can also be subjected to full-tooth hardening and single-tooth induction hardening. Single-tooth induction hardening is further divided into tooth surface & root hardening and tooth surface hardening.

+86-513-80311111 / +86-15050632597 [email protected]
contact us
PREV: WDA-110-xx-x Crossed roller slewing ring without gear NEXT:WDC-110-xx-x Crossed roller slewing ring without gear
  • Parameter
  • Dimensions
  • Get A Free Quote

Bearing No. Dimension(mm) Weight(kg) Ref. No
d d1 d2 D D1 D2 C C1 H B B1 N-M N1-M1 G
WDB-110-0220-01 140 170 142H9 300 270 298 h9 44 6 52 44 6 12-Φ18 12-Φ18 2/0-M10*1 16 08-0220-05
WDB-110-0220-02 140 170 142H9 300 h10 270 44 52 44 10 12-Φ18 12-Φ18 2/0-M10*1 16 110.14.0220.A
WDB-110-0270-01 190 220 192 H9 350 320 348 h9 44 6 52 44 6 16-Φ18 16-Φ18 4/0-M10*1 21 08-0270-04
WDB-110-0307-01 234 259 235H9 403.5 358 380 h9 47 6 55 45 10 24-Φ13 (28-1)-Φ13 2/0-M10*1① 26 08-0307-00
WDB-110-0400-01 305 336 306 H9 500 466 495 f9 63 8 75 63 8 30-Φ18 (30-1)-Φ18 0/3-M10*1 54 08-0400-00
WDB-110-0405-01 336 360 336H9 474 450 474 h9 41 10 46 41 10 30-Φ14 30-Φ14 3/0-M10*1 25 08-0405-05
WDB-110-0405-02 336 360 336 H9 474 450 474 h9 41 10 46 41 10 30-Φ14 (30-1)-Φ14 3/0-M10*1 24 110.14.0405.A
WDB-110-0414-01 342 368 344 H9 486 460 484 f9 46 10 56 46 10 24-Φ14 24-Φ14 2/2-M8*1 29 SUN 486×14 01 CC LM
WDB-110-0475-01 383 410 384 H9 589 540 565 f9 60 10 75 63 10 36-Φ16 (36-1)-Φ16 2/0-M10*1① 65 08-0475-08
WDB-110-0474-01 383 410 384 H10 589.5 540 565h10 60 20 75 58 10 36-Φ16 (36-1)-Φ16 2/2-M10*1① 58 110.18.0474.A
WDB-110-0544-01 472 498 474 H9 616 590 614 f9 46 10 56 46 10 32-Φ14 32-Φ14 2/2-M8*1 37 SUN 616×14 01 CC LM
WDB-110-0574-01 479 508 480 H9 700 640 670 64 4 77 64 10 36-Φ18 (36-1)-Φ18 0/2-M10*1 90 08-0574-08
WDB-110-0644-01 572 598 574 H9 716 690 714 f9 46 10 56 46 10 36-Φ14 36-Φ14 2/2-M8*1 44 SUN 716 ×14 01 CC LM
WDB-110-0675-01 573 604 574 H9 816 753 781h10 73 8 90 70 10 18-Φ22 18-Φ22 4/3-M10*1① 135 08-0675-00
WDB-110-0744-01 672 698 674 H9 816 790 814 h9 45.5 10 56 45.5 10 40-Φ13.5 40-Φ13.5 4/0-M8*1 52 110.14.0744.A
WDB-110-0744-02 672 698 674 H9 816 790 814 f9 46 10 56 46 10 40-Φ14 40-Φ14 2/2-M8*1 52 SUN 816×14 01 CC LM
WDB-110-0752-01 600 690 605 H9 900 848 / 105 / 125 110 53 30-Φ26 (30-1)-M24② 0/3-1/8-27NPT 267 110.36.0752.A
WDB-110-0823-01 717 753 718 H9 979 893 932 79 14 100 82 10 36-22 (36-1)-Φ22 4/4-M10*1① 270 08-0823-08
WDB-110-0844-01 772 798 774 H9 916 890 914 f9 46 10 56 46 10 40-Φ14 40-Φ14 2/2-M8*1 60 SUN 916×14 01 CC LM
WDB-110-0944-01 872 898 874 H9 1016 990 1014 f9 46 10 56 46 10 44-Φ14 44-Φ14 2/2-M8*1 67 SUN 1016×14 01 CC LM
WDB-110-0980-01 869 910 870 H9 1144 1050 1090 79 12 100 84 10 36-22 36-Φ22 4/4-M10*1① 248 08-0980-06
WDB-110-1094-01 1022 1048 1024 H9 1166 1140 1164 f9 46 10 56 46 10 48-Φ14 48-Φ14 2/2-M8*1 77 SUN 1116×14 01 CC LM

Notes:
① The oil hole of the outer ring is located at the end face of the ferrule.
② M24 is a blind screw hole with a depth of 35.
